学术演讲与海报

1. A novel electrochemical corrosion resistant solution for water-cooled diode laser stack

日期：2026年1月18日，16:30 - 16:50 PST

地点：Moscone South，2层，208会议室

演讲人: 侯栋，炬光科技工艺工程与材料部经理。拥有12年以上高功率半导体激光器器件开发与封装经验，累计获得30余项专利，在 SPIE 等光子学期刊发表技术论文15篇以上。

摘要：Water-cooled high power diode lasers have been widely applied in the field of medical health, industrial processing, and scientific research. Normally diode laser bars are bonded onto copper-based water-cooling plates to enhance output power and ensure effective heat dissipation. However, this approach results in electronic drift in water, triggering electrochemical corrosion in cooling plates. This issue manifests as corrosion in the anode channels and deposition in the cathode channels of a stack, ultimately leading to failure due to blockage, leakage, or burning of diode lasers. Research indicates that electrochemical corrosion is strongly correlated with the pH value and ion concentration in the water. Traditional solutions involve complex water treatment modules to maintain stable pH value and low ion concentrations with high cost and large volume. Another approach employs the application of ion exchange resins, which, however, require frequent replacement. In this study, we have proposed combined solutions to reduce electrochemical corrosion, including the protective layers design, reduction of erosion corrosion and improvement of cooler channels. A novel corrosion-inhibiting coolant was applied as an alternative to conventional deionized water without using any water treatment modules. Under these improvements, a 10-bar water-cooled diode laser stack produced by improved large channel cooling plate (LCC) was developed, which passed 3039 hours of quasi-continuous wave (QCW) life-time test without obvious power degradation. In contrast, traditional diode laser stacks using pure water exhibited significant electrochemical corrosion phenomena after 770 hours operation.

2. AI-accelerated high-fidelity volume fabrication of reflow-compatible micro-optics via UV imprinting

日期：2026年1月19日，16:45 - 17:05 PST

地点：Moscone South，3层，304会议室

演讲人：Libo Yu 博士，炬光科技首席工程师，拥有12年微纳光学器件产品与工艺研发经验，博士毕业于瑞士洛桑联邦理工学院（EPFL），专注于微光学方向，曾在多种国际期刊与会议发表学术论文与演讲。

摘要：Wafer-level optics (WLO) fabricated via UV imprinting enable scalable, cost-effective production of reflow-compatible micro-optics for compact optical modules in consumer electronics. However, form error (FE) introduced during the manufacturing process—primarily due to polymer shrinkage and mold deformation—necessitates 2 to 3 human-guided compensation cycles, significantly increasing development time and cost. This work presents an AI (artificial intelligence)- accelerated, physics-assisted prediction framework that reduces the development cycles by 30% while maintaining high replication fidelity. We propose a two-step cascaded prediction approach that explicitly decomposes the median FE into a dominant best-fit sphere (BFS) component and a higher-order rotationally symmetric irregularity (RSI), consistent with optical surface standards and physical deformation mechanisms in UV imprinting. In the first step, an AI model predicts the global spherical error as a low-dimensional scalar quantity from single-point diamond turning (SPDT) design parameters. In the second step, this physics-informed prediction is incorporated as an additional feature to regress the full FE profile, enabling focused learning of residual local deformations. The framework is evaluated on 69 distinct micro-optic designs using five-fold cross-validation and benchmarked against conventional single-stage AI models and human-guided compensation cycles. Results demonstrate that the proposed two-step approach achieves up to 3.3× improvement in peak-to-valley accuracy over single-stage prediction and closely approaches the accuracy of second-cycle human correction. Feature-importance analysis further confirms that the cascaded structure successfully decouples global shrinkage-driven deformation from local stress-induced irregularities, providing both improved prediction performance and physical interpretability. These results show that physics-assisted AI can eliminate one full development cycle for challenging designs, offering a practical pathway toward faster, lower-cost, and high-fidelity volume manufacturing of reflow-compatible micro-optics.

3. Next-generation microimprinting: enabling ultraflat base layers for high-end micro-optics applications

日期：2026年1月19日，17:05 - 17:25 PST

地点：Moscone South，3层，304会议室

演讲人：Mirco Altana，炬光科技高级研发工程师兼技术团队负责人，拥有15年以上洁净室微纳结构加工经验，曾主导多项母版与压印技术从研发到量产的转化，目前聚焦于微光学在汽车领域的应用及先进晶圆级压印工艺。

摘要：The development and experimental validation of a wafer-scale micro-imprinting system designed to produce ultra-flat polymer base layers for high-end micro-optical components on up to 300 mm glass wafers is presented. The machine combines a high-stiffness force path with nanometer-resolved gap control using multiple interferometric sensors and a programmable dispensing unit for controlled material pre-distribution. To quantify the intrinsic base-layer uniformity, imprint tests with flat, unstructured polydimethylsiloxane stamps of two thicknesses on borosilicate wafers and an epoxy-based UV-curable resin were performed, targeting a 30 μm base-layer thickness. The resulting films were characterized by stylus profilometry along orthogonal wafer axes. Stamp topographies were measured at identical coordinates to allow direct subtraction.

The experiments show that the dominant source of base-layer variation originates from stamp thickness non-uniformity rather than machine mechanics or resin distribution. After correction using the measured stamp profile, the residual wafer-scale variation shows a highly consistent shape for all tested conditions. Different dispensing strategies, from central puddle to star-shaped pre-distribution, change the corrected base-layer uniformity by less than 2 μm, indicating that material distribution is a secondary factor compared to the flatness of the machine chucks.

These results demonstrate that the new imprint system provides a mechanically stable and highly reproducible platform for micro-optical replication in the transitional regime between nano- and micro-imprinting, where uniform base layers are essential for high-quality optical performance.

4. Performance of micro-optics imprint technology

日期：2026年1月21日，10:50 - 11:20 PST

地点：Moscone South，3层，304会议室

演讲人：Toralf Scharf 博士，炬光科技微光学设计与工艺总监，拥有25年以上微纳制造技术与光学领域经验，曾发表论文200余篇，著有2部专著，曾任教于 EPFL 及纳沙泰尔微技术研究所。

摘要：Micro-optical components have been getting more and more popular in various applications in projection illumination. Often Microlens arrays are used to realize particular projection functions such as slanted angle street projection. Important is the lens surface definition and the quality of the array with respect to lens position and uniformity. To realize demanding applications of such array projectors the optical surface parameters are most important. Such projectors can contain more than 1000 lenses in a single optical component and if variation of the lens shape gets predominant the optical function will fail. In mass fabrication one has therefore to assure that no deviation happens in the whole fabrication process from mastering to imprint. During the fabrication process of the micro-optical components the surface is subject to geometrical deformations caused by shrinkage and aging of the tooling for instance. Changes are small but relevant and need a complex model that allows to include analysis of optical characteristics. At the quality level of today’s wafer level UV replication process, which can also realize freeform structures a simple analysis of radius of curvature and conic constant is not sufficient. It is therefore important to investigate at which point (or replication cycle) a controlled production is still possible. Only until this point than a correction of the surface shape is still possible. We have implemented an approach using Zernike polynomial fitting which allows us to see all changes down to noise of our metrology toolset and applied the model to a production data.

5. Freeform microlens arrays surface description

日期：2026年1月21日，16:50 - 17:10 PST

地点：Moscone South，3层，304会议室

演讲人：Toralf Scharf 博士。

摘要：Square and hexagonal footprint shaped lenses made by a wafer scale imprint process, could be a solution the enhance the lens fill factor for applications where imaging is not needed. Additionally, a mastering process using reflow technology will decrease the fabrication costs. But due to their complicated shapes that often need high-order polynomial descriptions for accurate modelling. Models based on the use of Zernike polynomials can help to describe and design the suitable surface for dedicated applications. Some examples will be presented.

6. Stamp material evaluations for next generation wafer level optics (Poster)

日期：2026年1月21日，18:00 - 20:00 PST

地点：Moscone West，2层，Poster Hall

摘要：Polydimethylsiloxane (PDMS) was evaluated, showing some limitations, e.g. swelling due to uptake of low molecular weight species after long time contact with epoxy, and subsequent deformation due to elasticity, as mold material in epoxy imprinting. The authors presented and demonstrated Polypropylene (PP) as potential replacement in wafer level optics (WLO) manufacturing, especially for high end imaging lens, which requires lens form error <0.5um, and position error <5um. With PP mold, the authors have achieved the lifetime of replication >30x, lens form error <0.1um, and roughness <5nm. A new process flow with combining injection molding optics (IMO) and WLO has been proposed.
